Detailed technical characteristics:
Educational trainer designed to teach the principles of magnetic circuits and their application to basic transformers.
You should understand the following topics:
-Understanding the main concepts of magnetism (Faraday's Law, alternating current induction, magnetic coupling).
-Understanding more advanced principles such as laminated configurations, eddy currents, permanent magnets, hysteresis, and losses.
-Define transformer regulation curves, their current ratio, and their impedance.
-Identify transformer characteristics such as coil resistance, reactance, inductance, saturation, voltage ratio, and polarity.
It include the following equipment:
-Three-module workstation
-Variable three-phase power supply
-DC voltmeter and ammeter
-AC ammeter
-AC voltmeter
-Flow meter
-Laboratory safety cable set
-Resistive load
-Inductive load
-Capacitive load
-Transformer
-Magnetic circuits and transformers (Work manual)
24 V AC power supply for wall mounting, 120 V 60 Hz
Synchronoscope function
Three-phase regulating autotransformer
Transformer
Power supply: 120-208V, 3F, 60 Hz.
The teaching bench have a total electrical power of no more than 2.4 kW. If a higher load is required, the necessary components and protections be used.
The necessary components and protections be used in order to ensure the safety of the equipment and users.
A safe and adequate type of connection be provided.
The necessary integrated protections be in place as a safety measure.
The bench be modular.
Technical Regulations and Standards that the product meet or exceed
The bank comply with certifications and technical standards that guarantee its safety, quality, and educational relevance.
