Detailed technical characteristics:
The learning system for the industrial wiring system contains all the equipment necessary to train students in the practical procedures for planning, installing, modifying, commissioning, and troubleshooting a typical three-phase industrial electrical installation.
Functions included:
- Electrical protection components to effectively protect students and equipment against
short circuits
- Circuit diagrams for industrial electrical engineering created with recognized software.
- Storage options for cable reels, protective conduits, tools,
components, and consumables
- Compact workstation
The supply includes the following components:
- Three-phase asynchronous motor,
- Industrial electrical cabinet,
- Control unit cabinet,
- 24 V DC power supply,
- Power contactor,
- Circuit breaker,
- Overload relay,
- Push buttons,
- Indicator lights,
- Emergency stop button,
- Terminal strip (voltage terminal, screw connection, insertion),
- Terminal strips for grounding,
- EMT protective conduits,
- Hoses.
Suitable for developing the following skills:
- Reading and understanding industrial wiring diagrams and plans
- Installing a distribution cabinet on a vertical surface
- Installing a distribution box on a vertical surface
- Drilling holes and bushings in the control cabinet for the installation of components and hardware
- Bending EMT conduits
- Angle cables and run them through protective conduits
- Install control and power components in the control cabinet
- Cut, strip, and crimp cables
- Wire control and power components
- Wire a three-phase asynchronous motor
- Label cables and components with marking tools
- Start up and test the electrical installation
