Detailed technical characteristics:
include at least the following equipment:
Synchronous motor/generator
Three-phase transformer bank
Lead-acid battery bank
Toothed belt
Laboratory safety cable assembly
Four-quadrant dynamometer/power supply with manual and computer control
24 V AC wall-mount power supply, 120 V 60 Hz
Four-pole squirrel cage motor with thermistor, 120 V
Resistive load, 120 V
Inductive load, 120 V 60 Hz
Capacitive load, 120 V 60 Hz
Transformer
Permanent Magnet DC Motor
Synchronization module/three-phase contactor
include the following work manuals:
DC circuits (Work manual)
DC circuits (Work manual (teacher))
Single-phase AC circuits (Workbook)
Single-phase AC circuits (Workbook (teacher))
Three-phase AC circuits (Workbook)
Three-phase AC circuits (Workbook (teacher))
Three-phase rotating machines (Workbook)
Three-phase rotating machines (Workbook (teacher))
Single-phase power transformers (Workbook)
Single-phase power transformers (Workbook (teacher))
Three-phase transformer banks (Workbook)
Three-phase transformer banks (Workbook (teacher))
Power factor correction (Workbook)
Power factor correction (Workbook (teacher))
Permanent magnet DC motor (Workbook (teacher))
Permanent magnet DC machine (Workbook)
Conventional DC Machines and Universal Motor (Workbook)
Conventional DC Machines and Universal Motor (Workbook (teacher))
Single-phase induction motors (Workbook)
Single-phase induction motors (Workbook (teacher))
The following accessories be included:
Digital multimeter
Mobile workstation
DC motor/generator, 120 V
Capacitor start motor, 120 V 60 Hz
Universal motor, 120 V
Three-phase variable power supply
Laboratory safety cable set
Timing belt
Storage shelves
Startup
Power supply: 120-208V, 3F, 60 Hz.
The teaching bench have a total electrical power rating of no more than 2.4 kW. If a higher load is required,
the necessary components and protections be used.
The necessary components and protections be used to ensure the safety of the property and users.
A secure and adequate connection be in place.
The necessary integrated protections be in place as a safety measure.
The bench be modular.
Technical norms and standards that the product meet or exceed
The bank comply with certifications and technical standards that guarantee its safety, quality, and educational relevance.
